Super Low Loss Flat Mirror

① Dimension D=φ3-φ25mm (tolerance ±0.1),H=3-8mm D:H > 4:1 (tolerance ±0.5)
D=φ26-φ100mm (tolerance ±0.1),H=6-25mm D:H > 5:1 (tolerance ±0.5)
② Coating area size: conventional size D12.7, coating area size 7.5; D25 coating area size 10, other coating area size can be customized
③ Surface accuracy: λ/ 10@632.8nm
④ Parallel error: <10"
⑤ Roughness: Ra0.12nm (Zygo profilometer) test area 173*173um full frequency measurement
⑥Coating requirement: wavelength 420nm-3000nm, reflection ≥99.999%, loss 2-3ppm, transmission 3-5ppm
Back anti-reflection;
⑦ Material: ULE, fused silica, single crystal silicon, sapphire;
Note: The specific indicators are not limited to the above scope, and can be customized according to user's needs.
Application:Laser gyro, high power laser, super stable laser, high precision optical detection

Send Inquiry Download

Product Description

Xi'an SNP Precision Optics CO., LTD: Your Trusted Super Low Loss Flat Mirror Manufacturer

At Xi'an SNP Precision Optics, we specialize in producing high-quality Super Low Loss Flat Mirrors. Our advanced manufacturing processes and stringent quality control ensure exceptional performance, making us a preferred supplier for industries demanding precision optics.

Super Low Loss Flat Mirror Introduction

Super Low Loss Flat Mirror is critical components in various optical systems, designed to reflect light with minimal loss and maximum precision. These mirrors are essential for applications requiring high reflectivity and low absorption, such as laser systems, optical cavities, and precision measurement devices.

Our product feature:

Ultra-smooth surfaces for minimal scattering
High reflectivity across a wide spectral range
Exceptional durability for long-term performance
Custom sizes and coatings to meet specific requirements

Whether you're working on cutting-edge research or developing high-power laser systems, our mirrors provide the reliability and precision you need.

Parameters

Parameter	Specification
Dimensions	Dimension D=φ3-φ25mm (tolerance ±0.1),H=3-8mm D:H > 4:1 (tolerance ±0.5) D=φ26-φ100mm (tolerance ±0.1),H=6-25mm D:H > 5:1 (tolerance ±0.5)
Coating Area	Customizable (standard: D12.7mm, 7.5mm area; D25mm, 10mm area)
Surface Accuracy	λ/10 @ 632.8nm
Parallel Error	<10"
Roughness	Ra0.12nm (Zygo profilometer) test area 173*173um full frequency measurement
Reflectivity	≥99.999% (420nm-3000nm)
Loss	2-3ppm
Transmission	3-5ppm
Materials	ULE, fused silica, single crystal silicon, sapphire

Note: Specifications can be customized to meet your unique requirements.

product-1-1

Applications

Our Super Low Loss Flat Mirror excel in various high - precision applications:

In laser gyroscopes for navigation systems, these mirrors ensure minimal signal degradation, allowing for highly accurate orientation and motion tracking in aircraft, ships, and unmanned vehicles. In high - power laser systems for industrial and research use, they can withstand intense laser energy while maintaining low losses, which is crucial for efficient material processing in industries like automotive manufacturing and for conducting advanced scientific experiments. Super - stable lasers for metrology and time - keeping rely on our mirrors to preserve the integrity of the laser beam, enabling extremely precise distance measurements and contributing to the accuracy of atomic clocks. For high - precision optical detection and measurement, such as in environmental monitoring for trace gas analysis or in semiconductor inspection for detecting minute defects, our mirrors play a vital role by reducing background noise and maximizing the signal - to - noise ratio.

Why Choose Us?

Industry-leading expertise: With our GJB9001C-2017 certification and status as a provincial-level "Specializing Ultra New" enterprise, we're at the forefront of optical technology.
Cutting-edge facilities: Our state-of-the-art clean rooms and advanced manufacturing equipment ensure consistent, high-quality production.
Customization capabilities: We work closely with you to develop mirrors that meet your exact specifications.
Rigorous quality control: Every mirror undergoes thorough testing to guarantee performance.
Responsive support: Our team of experts is always ready to assist with technical inquiries and after-sales support.

FAQ

Q: What is the typical lead time for Super Low Loss Flat Mirror?
A: Lead times vary depending on specifications and quantity. Please contact us for a precise estimate.

Q: Can you provide test data for each mirror?
A: Yes, we provide detailed test reports upon request, ensuring you have full confidence in our products' performance.

Q: Do you offer rush orders for urgent projects?
A: We understand time-sensitive needs and can accommodate rush orders when possible. Contact us to discuss your timeline.

Contact Us

Ready to elevate your optical systems with our Super Low Loss Flat Mirror? Our mirrors are engineered to minimize energy dissipation, delivering enhanced performance in even the most demanding applications. Reach out to our team at xachaona@163.com for expert advice, custom quotes.
